The CA8802AX amplifier is specifically designed for shaping and amplifying DMX512 digital lighting control signals, as well as 4-way distribution outputs. Each input interface adopts high-voltage isolation technology, which is suitable for shaping and amplifying DMX512 signals after distance transmission attenuation. It is also suitable for situations where complete electrical isolation is required between distribution output interfaces, input interfaces, and distribution output interfaces.
Due to the independent isolation between various interfaces, it is possible to avoid burning down the precise digital lighting control console due to issues such as control circuits, computer lights, and silicon boxes, ensuring the safe operation of the digital lighting control console. At the same time, it also ensures that the DMX signal can be transmitted to various lighting equipment normally, thereby improving the reliability of the entire digital lighting control system.
Product technical parameters:
★ Digital signal type: DMX512, and digital signals transmitted through RJ45 terminal interface;
★ 1 signal input, 1 through signal output (with electrical isolation between signal input and through signal), with signal input indicator light;
★ 8 signals are distributed and output through electrical isolation, each with signal indicator lights;
★ Signal connection socket: RJ45 terminals are used for both input and output ports
★ Input to output electrical isolation withstand voltage:>AC300V
★ Power supply: AC90V~240V, 50Hz/60Hz, 15W;
★ Size: 25 ×12.3 × 4.3 cm
★ Installation method: It can be fixed with screws or hung with a light hook for installation.
★ Weight: 0.75 Kg
